Wire Positioning: Braided Sleeving

Heyco® Braided Sleeving


Heyco® Braided SleevingUnderwriters' Laboratories Recognized under the Component Program of Underwriters' Laboratories File #-125761
Canadian Standards Association Certified by Canadian Standards Association File #LR-73368




  • A tough, cut-resistant oversleeving designed for protecting wire bundles and harnesses, hoses, nylon tubing and cable assemblies from mechanical damage and environmental hazards.
  • Braided sleeve expandable up to three times its own diameter, the open-weave construction can fit many applications, simplifying inventory.  Also, the open-weave allows for easy inspection of sleeved components and for easy break out of individual cables.
  • Full cable flexibility is maintained in any direction, even at low temperatures. Wires encased in Heyco Braided Sleeve can FLEX and bend as readily as if they had no protective oversleeving. Bundles can be flexed repeatedly without damage.
  • Braided Sleeve slips on quickly and is self-fitting over irregular shapes and contours.  No wire pulling compounds are required due to its low surface friction.   Slight tensioning after application makes for an even tighter fit.
  • The high tensile strength, damage-resistant filament braid:
    1)  protects against rough surfaces, sharp edges or corners;
    2)  resists scuffing and abrasion;
    3)  cushions against vibration and impact damage;
    4)  prevents condensation while allowing complete drainage;
    5)  dissipates heat and moisture;
    6)  does not degrade in most fluid environments.
  • Sleeved components are more organized and attractive!
  • Woven from polyester and flame retardant polyester yarns; temperature index 125°C, 230°C for short periods.
Swipe
Bundle Range Part No.   Part Dimensions
Minimum
Diameter
Maximum
Diameter
UL/CSA
Description
Nominal
Diameter
Quantity per
Spool
in.            mm. in.            mm.

Black

in.             mm. ft.              mtrs.
.090           2,3 .250           6,4 8980 BS 125 .125             3,2 2,000       610
8983 BS 125 FR
.130           3,3 .440          11,2 8985 BS 250 .250             6,4 1,000       305
8988 BS 250 FR
.250           6,4 .750          19,2 8990 BS 500 .500            12,7 500            152
8993 BS 500 FR
.500         12,7 1.250       31,8 8995 BS 750 .750            19,1
8998 BS 750 FR
.750         19,1 1.750       44,5 9000 BS 1250 1.250          31,8 250               76
9003 BS 1250 FR
1.250        31,8 2.750       69,9 9005 BS 1750 1.750        44,5
9008 BS 1750 FR
1.500        38,1 3.500       88,9 9010 BS 2.0 2.000        50,8
9013 BS 2.0 FR
1.750        44,5 4.500      114.3 9015 BS 2.5 2.500        63,5
9018 BS 2.5 FR
Standard Color:  Black.  White and others available at extra charge.(only in large quantities).
