Tri-Fold Blind Rivets

MAXIMUM SUPPORT: The GESIPA Tri-fold blind rivet forms three large folded legs that distribute the fastener's clamp-load over a large blind side head formation. This provides maximum support to brittle, soft or ductile material applications, and when used with oversized or irregularly shaped holes.

MULTI-GRIP: Tri-fold rivets feature multi-grip capability allowing one size to function in wide variations of material thickness, reducing the number of rivet sizes required.

CORROSION RESISTANT: The Tri-fold rivet's all aluminum construction offers excellent corrosion resistance.

POSITIVE MANDREL RETENTION: Tri-fold blind rivets have a locked mandrel core that won't rattle or fall loose into assemblies.

ALUMINUM RIVET/ALUMINUM MANDREL
Head Style	Rivet Dia. Nom.	GESIPA Part Number	Grip Range (Inches)	Hole Size Drill No.	Dimensions					Min. Strength (lbs.)
Head Style	Rivet Dia. Nom.	GESIPA Part Number	Grip Range (Inches)	Hole Size Drill No.	D	B	A	L	F	Shear	Tensile
Dome	5/32"	GAMD52ATF	.040-.118	.162-.167 #20	.161	.055	.312	.570	.680	200	225
		GAMD54ATF	.040-.250					.770	.880
		GAMD56ATF	.040-.375					.832	.942
		GAMD58ATF	.125-.500					.957	1.067
	3/16"	GAMD64ATF	.062-.250	.209-.221 #4	.205	.075	.385	.750	.875	350	450
		GAMD66ATF	.187-.375					.875	1.000
		GAMD68ATF	.312-.500					1.000	1.125
		GAMD610ATF	.437-.625					1.125	1.250
		GAMD612ATF	.563-.750					1.250	1.375

Tri-fold rivets are used in automotive applications such as plastic body panels, trim, and interior components.
