Flexible Grommetting

Click the product name or part number below to request a quote.

Extruded grommetting - roll form
  • Protects and insulates wires and cables from chafing against sharp chassis edges.
  • Serrated design particularly suited to irregularly shaped panel holes. (For regular round holes we recommend Heyco Snap Bushings or Heyco Shorty Bushings).
  • Depending on the chassis thickness, grommetting may grip tightly by itself. If not, a touch of epoxy will keep it in place.
  • A wide range of sizes fits chassis thicknesses from .036 (0.9 mm) to .250" (6.4 mm).
  • The most cost effective way to protect wire and cables from sharp edges.
  • Six sizes can be cut to fit for no waste.
Filter:
  Product Name  Color  Max. Panel Thickness [inches]  Max. Panel Thickness [mm]  Thickness - A [inches]  Thickness - A [mm]
2220
2220
Black  0.036  0.9  0.032  0.8  Add to Quote

2222
2222
Black  0.071  1.8  0.032  0.8  Add to Quote

2224
2224
Black  0.105  2.7  0.032  0.8  Add to Quote

2226
2226
Black  0.164  4.2  0.047  1.2  Add to Quote

2228
2228
Black  0.187  4.8  0.047  1.2  Add to Quote

2230
2230
Black  0.25  6.4  0.047  1.2  Add to Quote

2221
2221
Natural  0.036  0.9  0.032  0.8  Add to Quote

2223
2223
Natural  0.071  1.8  0.032  0.8  Add to Quote

2225
2225
Natural  0.105  2.7  0.032  0.8  Add to Quote

2227
2227
Natural  0.164  4.2  0.047  1.2  Add to Quote

2229
2229
Natural  0.187  4.8  0.047  1.2  Add to Quote

2231
2231
Natural  0.25  6.4  0.047  1.2  Add to Quote

Displaying 1 to 12 (of 12 products) Result Pages:  1
